Saint gobain Pharmed BPT Tube
- Models: Pharmed BPT
- Maximum channel quantity:
- Reference flow rate:
■ Pharmed BPT is imported peristaltic pump tube;
■ Service life 1,000 hours;
■ Beige opaque, resistant to ozone and UV rays to protect the light-sensitive fluid;
■ No cytotoxicity and hemolysis, ideal for tissue and cell culture;
■ Air tightness 60 times than silicone tube, can be welded for heat sealing;
■ ETO, can be repeatedly sterilized under high temperature and pressure, 2.5Mradγ sterilization;
■ Bio-compatibility up to ISO10993 standard.
Saint Gobain Pharmed BPT tube is an imported high-performance peristaltic pump tube with a lifespan of up to 1,000 hours. The tube is beige and opaque, with excellent resistance to ozone and ultraviolet light, effectively protecting photosensitive liquids. Its non-cytotoxic and non-hemolytic properties make it an ideal choice for tissue and cell culture applications.
The gas tightness of the Pharmed BPT tube is 60 times greater than that of silicone tubes and can be sealed, ensuring the safety of fluid delivery. It is designed to support ethylene oxide (ETO) sterilization and can withstand high-temperature and high-pressure sterilization, with a 2.5 Mrad gamma sterilization capability. The tube’s biocompatibility meets ISO 10993 standards, ensuring reliable applications in the biomedical field.
Product Configuration
| Product Parameters | |
| Product Name | Tygon PharMed BPT |
| Temp resistance | -50℃-135℃ |
| Hardness | 64A |
| Sterilization | Can be repeatedly heated and pressurized. |
| Certification | REACH，RoHS，USP Class VI，FDA，NSF以及ISO10993 |
| Life | Peristaltic pump extrusion life: ≥1000h |
| Color | Yellow and opaque |
| Advantages | Excellent resistance to acids, alkalis, and oxides, as well as excellent resistance to general chemicals. The PharMd BPT hose is easy to clean and disinfect. Due to its impermeability to visible and UV light, the PharMd BPT hose helps to protect light sensitive fluids. |
| Applications | Squeezing tube with peristaltic pump, sensitive cell culture, fermentation, synthesis, separation, purification, experimentation, medical, pharmaceutical, food, etc. |
| Note | 1. The values are provided by the official Saint Gobain for reference only. 2. Condition for hose life test: Using a 3-roller peristaltic pump, deliver clean water at a speed of 600rpm and 23 ℃ in an environment without pressure at the inlet and outlet, and continue running until the hose cracks. |
Product Specifications
| Tygon BPT tube detailed dimensions（Unit: mm） | ||||||||||||
| BPT | AY2491789 | AY2492801 | AY21X1518 | AY242606 | AY242005 | AY242007 | AY242012 | AY242007 | AY242022 | |||
| Tube no. | 1*1 | 2*1 | 3*1 | 4*1 | 13# | 14# | 19# | 16# | 25# | 17# | 18# | |
| ID（mm) | 1 | 2 | 3 | 4 | 0.8 | 1.6 | 2.4 | 3.2 | 4.8 | 6.4 | 7.9 | |
| OD（mm) | 3 | 4 | 5 | 6 | 4 | 4.8 | 5.6 | 6.4 | 8 | 9.6 | 11.1 | |
| Wall Thickness（mm) | 1 | 1.6 | ||||||||||
| Hose Pressure-bearing（Mpa）） | Continuous | 0.1 | 0.1 | 0.1 | 0.1 | 0.17 | 0.17 | 0.17 | 0.17 | 0.14 | 0.1 | 0.07 |
| Interval | 0.1 | 0.1 | 0.1 | 0.1 | 0.27 | 0.27 | 0.27 | 0.27 | 0.24 | 0.14 | 0.1 | |
| BPT | AY242018 | AY242029 | ||||||
| Tube no. | 15# | 24# | 35# | 36# | 26# | 73# | 82# | |
| ID（mm) | 4.8 | 6.4 | 7.9 | 9.6 | 6.4 | 9.6 | 12.7 | |
| OD（mm) | 9.6 | 11.2 | 12.7 | 14.4 | 13 | 16.2 | 19.3 | |
| Wall Thickness（mm) | 2.4 | 3.3 | ||||||
| Hose Pressure-bearing（Mpa） | Continuous | 0.17 | 0.17 | 0.14 | 0.1 | 0.27 | 0.17 | 0.2 |
| Interval | 0.27 | 0.27 | 0.24 | 0.14 | 0.27 | 0.27 | 0.27 | |
| Tube no. | 88# | 92# | 86# | 90# | |
| ID（mm) | 12.7 | 25.4 | 9.5 | 19 | |
| OD（mm) | 22.3 | 35 | 21.6 | 31.6 | |
| Wall Thickness（mm) | 4.8 | 6.3 | |||
| Hose Pressure-bearing（Mpa） | Continuous | 0.14 | 0.25 | 0.25 | 0.25 |
| Interval | 0.14 | 0.3 | 0.3 | 0.3 | |
