These compact transmitters turn pressure of liquids, gases and steam into an electrical signal for a PLC, logger or controller. The range includes plug-in, threaded, flush-diaphragm, sanitary and high-temperature types.
At a glance
- Ranges from -0.1 MPa vacuum up to 250 MPa depending on model
- Accuracy options of 0.1, 0.2 and 0.5 percent of full scale
- Outputs: 4-20 mA, 0-10 V, 0.5-4.5 V, RS485 and I2C
- Stainless steel 304 or 316 wetted parts; PTFE, PVDF and PP options
- IP65 to IP68; some models carry Ex ia IIC T6 Ga marking
- Threads G1/2, G1/4, M20x1.5 and others; sanitary clamp versions
Where it is used in Malaysia
- Water supply, booster pump and irrigation systems
- Fire-fighting pipelines and hydrants
- Food, beverage and pharmaceutical plants (sanitary types)
- Air compressors, hydraulic machines and cranes
- HVAC chilled water and refrigeration lines
- Boilers, steam lines and cooling towers
Models in this range
How it works
A pressure-sensitive diaphragm bends under pressure and a sensing element converts the movement into a voltage. On-board electronics turn it into a standard output such as 4-20 mA that your controller can read.
Order from AIBS
Ai Business Solutions Sdn Bhd supplies this product in Malaysia and across Asia Pacific. Send us a quote request with the model, the quantity and your application, and we will reply within one working day.
