The TR323 is a small 5G router for sites that need fast, low-delay connectivity. It brings 5G NR, or lower-cost 5G RedCap, to your devices and also reads RS485 equipment.
At a glance
- 5G NR, 5G RedCap or 4G LTE CAT 4 to choose
- 2 Gigabit Ethernet ports, 2 RS485, 1 RS232 debug port
- Dual SIM for failover; optional 2.4 GHz Wi-Fi and GNSS
- Built-in OS; Python, C/C++ and Node-RED (option)
- Modbus RTU/TCP and MQTT; VLAN (option)
- DIN-rail mounting, 104 x 78 x 24 mm
Where it is used in Malaysia
- Remote sites needing a fast backup or main internet link
- Cameras, kiosks and digital signage over 5G
- Industrial IoT where 4G speed is not enough
- Smart building and energy gateways on a mobile network
- Temporary sites and events
How it works
The router connects to the 5G or 4G network and shares the link with your Ethernet devices, while its RS485 ports bring serial equipment into the same network. The second SIM takes over if the first one loses signal.
Order from AIBS
Ai Business Solutions Sdn Bhd supplies this product in Malaysia. Send us a quote request with the model, the quantity, the network (4G, 5G or LoRa) and the devices you want to connect, and we will reply within one working day.
