Add WiFi and Bluetooth to a product with only a few wires. Use serial commands to join a network and send data to a cloud service or app.
At a glance
Models for 802.11 b/g/n, 802.11 a/b/g/n/ax and BLE 5.0 / 5.2 / 5.4
WiFi up to 20 dBm, BLE up to 18 dBm
AT commands, UART and GPIO control
WEP, WPA, WPA2 and WPA3 security
Low-power version with 30 uA standby shutdown
Small SMD size 24 x 16 mm
Where it is used in Malaysia
Smart home appliances and lighting
Energy meters and sensors
Wearables and handheld tools
Retail and logistics tags
Prototypes and OEM controllers
How it works
The module handles WiFi and Bluetooth by itself. Your controller sends data through the UART, and the module sends it to the network.
Order from AIBS
Ai Business Solutions Sdn Bhd supplies this product in Malaysia and across Asia Pacific. Send us a quote request with the model, the quantity and your application, and we will reply within one working day.
WiFi
IEEE 802.11 b/g/n (and WiFi 6 on selected model)
Bluetooth
BLE 5.0 / 5.2 / 5.4
Interface
UART, GPIO, I2C, PWM, SPI
Supply
3.3 V
Package
SMD, 24 x 16 x 2.1 mm
Operating temperature
-40 to 85 C
Ask about Serial WiFi and Bluetooth BLE Combo Modules (WiFi 6 + BLE 5.4, UART, Low Power)
Questions about specifications, stock, lead time or compatibility? We reply within one working day.
Need a different model, size or accessory? Add it to your quotation as an item not listed on our website.
Plug-and-play 4G modules: router boards that share a SIM connection by WiFi and Ethernet, a compact LTE Cat.1…
Price on request
Serial WiFi and Bluetooth BLE Combo Modules (WiFi 6 + BLE 5.4, UART, Low Power)
Quotation within 1 working day
Can’t find what you need? We’ll source it.
Send us a product list, a specification or a description — even for items not listed on our website — and our sales team will reply with a formal quotation.
